Banknote Counter and Sorting Money Counting Machine with 4.3” Touch Screen, UV/MG/IR Detection, Dual CIS Sensors – Gray

Description

The Professional 1+1 Pocket Banknote Counter and Sorting Machine is a high-performance solution for banks, retail businesses, and cash-handling institutions. Equipped with a 4.3-inch TFT touch screen, it offers intuitive operation and advanced counting accuracy. The dual-pocket design allows continuous counting—automatically separating counterfeit, suspect, or different denomination notes into a reject pocket.
This machine supports

Description

The Professional 1+1 Pocket Banknote Counter and Sorting Machine is a high-performance solution for banks, retail businesses, and cash-handling institutions. Equipped with a 4.3-inch TFT touch screen, it offers intuitive operation and advanced counting accuracy. The dual-pocket design allows continuous counting—automatically separating counterfeit, suspect, or different denomination notes into a reject pocket.
This machine supports multi-currency detection and includes UV (ultraviolet), MG (magnetic), IR (infrared), and dual CIS image sensors for reliable counterfeit recognition. With four operating modes (MIX, SDC, SG, CNT), it can sort by denomination, orientation, and face. The counting speed is adjustable (800/1000/1200 notes per minute), ensuring flexible performance for different needs.
Connectivity options include USB, LAN, RS232, and PC ports, supporting data collection, report printing, and software updates. Built-in protection features prevent overheating and mechanical jams, making it durable and safe for heavy daily use.

SpecificationsParameterDetailsProduct NameProfessional 1+1 Pocket Banknote Counter and Sorting MachineMaterialIndustrial-grade ABS housingDisplay4.3” TFT Touch ScreenCounting Speed800 / 1000 / 1200 notes/min (MIX, SDC, SG); up to 1500 notes/min (CNT)Detection SystemUV, MG, IR, Dual CISSorting FunctionsDenomination, Face, Orientation, Version, Ink, Hole DetectionHopper Capacity500 pcs (with hopper guide)Reject Pocket Capacity100 pcsStacker Capacity200 pcsPower Supply100–240V, 50–60HzPower Consumption≤170W (Max)Noise Level60–75 dBPortsUSB, LAN, RS232, PCProduct Size265 × 295 × 285 mmWeight10 kgPackage Size420 × 430 × 460 mmOptional FeaturesBuilt-in or External PrinterProtection FeaturesOverload protection, automatic jam detection, overheat safetyUsage Instructions

• Setup: Place the machine on a stable, horizontal surface and connect the supplied power cord.
• Power On: Switch on the power button located at the back of the unit.
• Currency Selection: Press the CUR button or touch the currency icon to choose the desired currency.
• Counting Mode: Use MODE to select between MIX, SDC, SG, or CNT mode.
• Start Counting: Load banknotes into the hopper and press START/STOP. The machine will automatically sort, count, and display the total.

Recommendations

1. Daily Cleaning: Use a soft, lint-free cloth with diluted mild detergent; avoid spraying liquids directly.
2. Bill Path Maintenance: Clean sensors regularly with a 50/50 mix of isopropyl alcohol and water; ensure the path is dry before operation.
3. Avoid Exposure: Keep away from sunlight, dust, and liquids to protect sensors.
4. Power Care: Always unplug the machine before cleaning or moving.
5. Software Updates: Use the USB port to install updates as provided by the distributor for optimal performance.
